ALAS XX

Precision at its best

EDePro | Alax XX
Land Attack 5th Generation Cruise Missile

ALAS XX, a multipurpose Surface-to-Surface missile system, underdevelopment of Yugoimport SDRP for Serbian Army, personifies top-notch precision-strike, time-critical, guided munition which unlocks completely new capabilities of the modern Armed Forces artillery. The system is integrated on a modular self-propelled missile launcher “OGANJ”, the first Serbian artillery weapon capable of firing missiles. Each vehicle is capable of carrying 4 to 8 containers with missiles.

The main ALAS system advantage is the new ability for firing in non-line of sight scenarios (NLOS) based on embedded IMU, enabling automatic navigation of the missile to the target.  The capability to receive target coordinates from the third party (other force, UAV, drone, or any other unit detecting a target) defines ALAS as a pioneer of the 5th generation of cruise missiles. Interaction with other combat units facilitates precision creating a matrix of sensors and effectors to find the line-of-sight targets, without the need for extra manoeuvres.

ALAS XX has a maximum range of 25 kilometres, with the missile flying at an altitude less than 500 meters at a cruise speed of 130-150 meters per second.

Furthermore, the following development phase will bring to life an integrated tandem warhead capable of penetrating over 1,000 mm RHA, suitable to engage facilities, hardened targets, tanks, and armoured vehicles. Modern sensor-integrated warhead technology is synonymous with intelligent and highly efficient ammunition, enabling our customers to be at the fore forefront of intelligent Armed Forces transformation.

Key Features:

  • Integrated tandem warhead with penetration over 1000 mm RHA
  • Initial alignment
  • Aided INS (AINS) Navigation based on INS, GPS, and altimeter (based on availability)
  • Midterm guidance – trajectory guidance based on pre-set trajectory points from GCS
  • Terminal guidance based on Homing Head signal has an absolute accuracy of 1 m
  • Target spotting maximum distance up to 12 km*
  • Target recognition maximum distance up to 10 km
  • Track & Lock-On target range up to 7 km
  • Target Tracking aborting is available at any time during the flight
  • Possibility of the target re-track for target detail tracking or for setting up the new target
  • Communication with Ground Control Station (GCS) during Mission Setup & Flight
  • Continuous in-flight monitoring of all missile and communication/control subsystems: (Booster motor separation control; Missile velocity control; Warhead arming and disarming);
  • Abort mission function (Manual, from GCS; Automatic, based on predefined criteria)
